Manufacture

ODG is one of the most advanced gear manufacturers with the latest equipment from OEMs such as Liebherr, Kapp, Koepfer, and Klingelnberg. ODG’s manufacturing core competencies lie in gear hobbing, shaping and grinding

Module (DP) Diameter mm (Inch) AGMA Quality (2015-1-A01)
Hobbing 1.6 – 8.0 (40.0 – 3.2) Up to 500mm (20″) AGMA A6
Shaping 1.6 – 12.0 (40.0 -2.1) Up to 500mm (20″) AGMA A6
Gear Grinding 1.6 – 10.0 (40.0 – 2.5) Up to 500mm (20″) AGMA A3

ODG goes beyond just gear manufacturing with over 150+ machine tools for turning, milling, drilling, broaching, key seating, and cylindrical grinding.

  • 1 MORI SEIKI NL3000 CNC Lathe to 1 MORI SEIKI NL3000 MC/700 CNC Lathe
  • 1 MORI SEIKI NL 2500 SMC / 500 CNC Lathew/Sub-Spindle
  • 1 OKUMA & HOWA 2SP-V40 Twin Spindle Vertical Lathe
  • 1 HWACHEON TTC-10 Twin Spindle CNC Lathe
  • 2 DAEWOO PUMA 300C CNC Lathe
  • 1 DAEWOO PUMA 250M 3-Axis CNC Lathe
  • 1 DAEWOO PUMA 240B CNC Lathe
  • 3 EMAG VL-5 Vertical Turning Centre
  • 1 EMAG VL-3 Vertical Turning Centre
  • 1 DAEWOO PUMA 200CX CNC Lathe
  • 2 TARNOW 22” x 60” Engine Lathe 1 – TRAK TRL 2460V CNC Lathe
  • DAWOO PUMA V55M CNC Lathe
  • 2 MAKINO a81 CNC Horizontal Machining Centres
  • 1 MAZAK 20” x 40” NEXUS 510C CNC Vertical Machining Centre
  • 1 MAZAK VCU 500 CNC Vertical Machining Centre  w/ Rotary pallet changer
  • 1 DAEWOO MYNX Vertical Machining Centre
  • 1 DAHLIH Vertical Milling Machine  w/ Vertical and Horizontal Spindles
  • 1 TRAK MILL LPM
  • 1 FIRST MODEL LC-20 VSG 10” X 51” Vertical Mill
  • ​1 LIEBHERR LSE500 CNC Gear Shaper
  • 1 LORENZ LS304 CNC Gear Shaper
  • 1 TOS CNC 500mm Gear Shaper OHA50B
  • 1 LORENZ LS304 CNC Gear Shaper
  • 1 LIEBHERR LC500 CNC Gear Hobber
  • 4 LIEBHERR LC382 CNC Gear Hobber
  • 1 KOEPFER 200 CNC Gearhobber
  • 1 Tooth Rounding Machine
  • 1 Gleason Genisis 400 HCD CNC Gear Hobber w/ auto load unload and chamfer cut/ deburr station
  • ​1 STUDER FAVOURIT CNC Cylindrical Grinder
  • 1 SEIWA CNC Hob Grinder
  • 1 TECHNOIMPEX Cylindrical Grinder 10” x 30”
  • 1 CHEVALIER FSG-3A818 Surface grinder
  • 3 KAPP KX300 Gear Grinder
  • 1 Klingelnberg Hofler Viper 500W CNC Internal external Gear grinder
  • 1 STUDER FAVOURITE CNC Cylindrical Grinder w/ internal grinding
  • 1 KLINGELNBERG P65 Lead & Involute Checker
  • 1 Vibration Analyser 3-axis Dalimar Accelerometer
  • 1 GLEASON 300GMS Lead & Involute Checker
  • 1 DALIMAR 3-axis Vibration Analyzer Accelerometer
  • 1 NATIONAL INSTRUMENTS Vibration Analyzer
  • 1 MITUTOYO Crysta Apex CMM S9108
  • 1 MITUTOYO Bright CMM A710
  • 1 MITUTOYO Bright CMM A910
  • 1 MITUTOYO Manual CMM BH706
  • 1 MITUTOYO Manual CMM B706
  • 2 PENTA GEAR Over Pin Gauge
  • ​1 KLINGELNBERG P40 Lead & Involute Checker
  • 1 MITUTOYO CNC CMM 91085
  • 1 MITUTOYO CMM B706
  • 1 M&M Over Pin Gauge
  • 1 STARRETT Optical Comparator HB400-22IE
  • 1 MAHR Marshaft Scope XXXXX
  • 1 MITUTOYO ATK600 Hardness Tester
  • 1 VERSITRON AT130 Hardness Checker
  • 1 KLINGELNBERG Double Flank Roll Checker
  • 1 MAGG Double Flank Roll Checker
  • 1 M&M Double Flank Roll Checker
  • 2 VARI-ROLL Double Flank Roll Checker

Specimen Preparation

Sectioning:
-Shafts up to 5.25” in Diameter
-Opening for shafts of any length

Mounting:
-Ability to mount specimen 1”-2” mold sizes

Polishing:
-Prepare mold for analysis
-leaves part with a mirror finish
-Dual polishing wheels for multiple grit sizes

Specimen Analysis

Inverted Microscope:
-Analysis of grain size and structure
-1.3 MegaPixels
-Clemex vision lite for image analysis
-Grain size ASTM E112 Analysis Routine

Micro-Hardness Tester:
-Analysis of hardness using Vickers or knoop
-Analysis of case depth
-NIST traceable test block

Macro-Hardness Tester:
-1 Mitutoyo ATK600 Hardness Tester
-1 Versitron AT130 Hardness Checker
